Manual mains changeover 3AC 230/400V 50Hz
– Connection fuse max. 63A
– All-pole disconnection, TN-S or TT system
– NO TN-C mains in the customer system
suitable for
Sunny Island 4.4M-12 / -13 à partir de la version du micrologiciel 1.00.xx.R
Sunny Island 6.0H-12 / -13 à partir de la version du micrologiciel 1.00.xx.R
Sunny Island 8.0H-12 / -13 à partir de la version du micrologiciel 1.00.xx.R
Country availability: France, Netherlands, Belgium
For further technical information, please download the documentation.
Note
Matchcode: 1PH_EPC_SMA.SI_BBDAP_12KW_1PH_PREP_FR_1.0
Item no.: 10013676
Compatible with: SMA
Phases: 1 phase
Mains disconnection: All-pole
Max. thermal throughput: 12 kW
Country code: France, Netherlands, Belgium
NA protection: no
Source switch: no
Nominal voltage: 230V
Nominal frequency: 50/60 Hz
Short-circuit current: 10 kA
Back-up fuse: 63 A
Operating temperature range: -25°C to +40°C
Humidity: 5% to 95%
Protection class: II
Dimensions WxHxD: 338x622x161 mm
Weight: 10.5 kg
Housing: Polymer
