CANCELLED
Battery inverter:
1 x Sunny Boy Storage – suitable for 3.7/5.0/6.0
PV inverters:
2 x Sunny Boy – suitable for 3.0/3.6/4.0/5.0*
PV inverter – 1PH:
2 x Sunny Boy – optional 3.0/3.6/4.0/5.0
PV inverter – 3PH:
1 x Sunny Tripower 3.0 to 10.0 or 5000TL to 12000TL (no support for battery-backup operation!)
PV generation meter:
Connection option!
Monitoring & Control:
integrated SMA – Backup Controller
prepared for SMA Home Manager 2.0 or SMA Energy Meter
– SMA Sunny Home Manager 2.0 or
– SMA Energy Meter
Mains form:
3PH 230/400V – TT or TN-S system
For further technical information, please download the documentation.
Note
Matchcode: 3PH_SMA.ST6.0_1STP12_2SB5_BBDAP_20KW_1PH_PREP_DACH_1.5
Item no.: 10012856
Compatible with: SMA
Phases: 1 phase
Mains disconnection: All-pole
Throughput power: <= 35kW
Max. thermal throughput: 12 kW
Country code: Germany, Austria, Switzerland (D-A-CH)
NA protection: no
Source switch: no
Nominal voltage: 230/400V
Nominal frequency: 50 Hz
Short-circuit current: 10 A
Back-up fuse: 63 A
Operating temperature range: -25°C to +40°C
Humidity: 5% to 95%
Protection class: II
Dimensions WxHxD (mm): 448x622x161 mm
Weight: 12 kg
Housing: IP65
Net shape: TN-S, TT
