Enwitec fireman’s switch Santon-1000-10x2R-T50-BC-PES-1.2
Fireman’s switch from enwitec. Public buildings, industrial buildings and warehouses in particular are subject to increased safety requirements. enwitec combines conventional connection technology for PV systems with the PVSEC disconnector and thus offers individual and freely scalable solutions up to the megawatt range. This can be used to de-energize the DC cables installed in the building.
Matchcode: Santon-1000-10x2R-T50-BC-PES-1.2
Article no.: 10014856
System voltage VDC: 1000VDC
MPP tracker: 10
Strings in input per MPP: 2
Output strings per MPP: 2
Overvoltage protection: I + II/BC
Connection type: Screw connection
String fuse: No
Monitoring option: NO auxiliary contacts from disconnector
Load-break switch: Yes
Housing: Polyester
Dimensions (WxHxD): 800 x 600 x 300 mm
