enwitec “BAT BREAKER” battery fuse for the BYD “Battery-Box” PV energy storage system
Number and type of battery chargers / inverters: Max. 3 x SMA Sunny Island
Number and type of energy storage units: Max. 3 x BYD 48V Battery-Box (all types)
Matchcode: BAT BREAKER-Spec.BYD-3xAccu-3xCharger_standard_KS
Item no.: 10012417
Fuse type: Magnetic-hydraulic
Number of battery chargers/inverters: Max. 3 x Sunny Island
Number of battery parallel strings: Max. 3 x BYD 48V Battery-Box (all types)
Rated current: 200A per potential
Triggering characteristic: “DC Long Delay”
Switchable max. short-circuit current: 10kA
Connection to charger/inverter: M10 cable lug
Connection to battery: M10 cable lug
Temperature range up to: 0°C to +45°C
Relative humidity: up to 85%, non-condensing
Battery cabinet dimensions WxHxD: 400x400x132mm without screw connection
Total weight: 9 kg
